Slimline range
11.50kW
14.00kW
ARTA45LATU
| Product Category | Slimline |
| Product Range | Slimline range |
| Capacity | 11.50kW Cooling 14.00kW Heating |
| Model Number | ARTA45LATU |
Technical Specifications
| Indoor unit | ARTA45LATU |
| Outdoor unit | AOTA45LCTL |
| Operation Type | Reverse Cycle |
| Power Source V/Ph/Hz | 230 / 1 / 50 |
| Cooling Capacity kW (Rated (Min - Max)) | 11.50 (4 - 13.3) |
| Heating Capacity kW (Rated (Min - Max)) | 14.00 (4.2 - 15.5) |
| Input Power Cooling kW (Rated (Max)) | 3.56 (5.02) |
| Input Power Heating kW (Rated (Max)) | 4.02 (5.02) |
| EER Cooling kW/kW | 3.23 |
| COP Heating kW/kW | 3.48 |
| Star Rating Cooling (0-10) (Hot / Average / Cold) | 2 / 2 / 2 |
| Star Rating Heating (0-10) (Hot / Average / Cold) | 2.5 / 2 / 1.5 |
| Total Cooling Seasonal Performance Factor Residential kW (Hot / Average / Cold) | 3.949 / 3.689 / 3.766 |
| Heating Seasonal Performance Factor Residential kW (Hot / Average / Cold) | 4.16 / 3.595 / 3.066 |
| Total Cooling Seasonal Performance Factor Commercial kW (Hot / Average / Cold) | 4.184 / 4.187 / 4.426 |
| Heating Seasonal Performance Factor Commercial kW (Hot / Average / Cold) | 4.161 / 3.831 / 3.27 |
| Running Current amps (Cooling / Heating) | 14.9 / 16.8 |
| Moisture Removal l/hr | 4 |
| Indoor Sound Pressure Cooling dBA (High / Quiet) | 42 / 28 |
| Indoor Sound Pressure Heating dBA (High / Quiet) | 42 / 28 |
| Outdoor Sound Pressure dBA (Cooling / Heating) | 55 / 55 |
| Outdoor Sound Power dBA | 69 |
| Static Pressure Range PA (Min to Max) | 30 to 150 |
| Air Circulation (Indoor - High Fan) Cooling l/sec | 583 |
| Air Circulation (Indoor - High Fan) Heating l/sec | 583 |
| Indoor Unit Dimensions mm (Height x Width x Depth) | 270 x 1135 x 700 |
| Indoor Unit Weight kg | 40.00 |
| Outdoor Unit Dimensions mm (Height x Width x Depth) | 1290 x 900 x 330 |
| Outdoor Unit Weight kg | 86.00 |
| Piping Connects mm Ø (Liquid / Gas) | 9.52 / 15.88 |
| Pipe Length m (Max (Precharged)) | 50 (20) |
| Max Height Difference m | 30 |
| Operation Range Cooling °CDB (Min to Max) | -15 to 46 |
| Operation Range Heating °CDB (Min to Max) | -15 to 24 |
| Refrigerant Type | R410A |
| Refrigerant Amount g | 3,350 |
Show all specifications
Collapse all specifications
Dimensions
Ducted Slimline Indoor Model ARTA45LATU
Ducted Slimline Outdoor Model AOTA45LCTL
What’s included in your purchase
ARTA45LATU
Indoor Unit
AOTA45LCTL
Outdoor Unit
Optional Parts
UTB-TUD
Wired Remote Controller
UTY-LRHYM
Wireless Remote Controller - Wireless Remote Controller & Infra-Red Receiver Kit
UTY-RVNYN
Wired Remote Controller - Backlit Wired Controller
UTD-ECS5A
External Control Wiring Kit
UTD-RS100
Remote Temperature Sensor
UTY-XWZXZ3
External Connect Kit
UTZ-PX1NBA
Drain Pump Unit
Key features
Slim and compact design perfect for discreet installation.
-
Auto RestartShould there be a temporary loss of power, the unit will automatically restart itself in the same operating mode, once the power is restored.
-
Auto ChangeoverThe unit automatically switches between operating modes based on the temperature setting and room temperature.
-
Blue Fin Heat ExchangerCorrosion-resistance of the heat exchanger in coastal areas has been improved by blue fin treatment of the outdoor unit heat exchanger.
-
Connectable Distributing DuctSystems are capable of attaching a field-supplied branch ducts distributing the airflow.
-
Connectable Fresh Air DuctAllows introduction of fresh air to the occupied space.
-
Economy ModeLimits the maximum operation current, and performs operation with the power consumption suppressed.
-
Filter SignSelect appropriate intervals for displaying the filter sign on the indoor unit according to the estimated amount of dust in the air of the room.
-
On-Off TimerON-OFF timer can be set to operate once every 24 hours.
-
Program TimerThis timer allows selection of one of four options. ON, OFF, ON ––> OFF, or OFF ––> ON.
-
Weekly TimerDifferent ON-OFF times can be set for up to 7 days.
This product is part of the Residential and Commercial Slimline range
